Bubble 2 - Page 4

C
C
O
O
N
N
T
T
R
R
O
O
L
L
S
S
L
L
I
I
S
S
T
T
1. 1. Oil flow control knob. (You to set)
2. 2. Water temp. control knob. (You to set)
3. 3. Safety thermostat. (Automatic)
4. 4. Oil trip lever. (You to set and automatic)
The oil trip safety fuel cut off lever is situated on the right hand side of the oil control valve.
o LIFT FOR OIL OFF.
o PRESS DOWN FOR OIL ON
(To gain access to it, remove the centre panel of the fender top, and put your hand in to the left
hand side, you will feel a small bent metal lever projecting out from the topside of the valve.)
The lever is designed to cut off the fuel supply into the oil control valve either manually or
automatically consequently stopping the stove by shutting off the oil supply from the oil control
valve.
It is also designed to warn you of a problem with the oil control valve, if the stove goes out
unexpectedly and you can’t get the trip lever to trip on there are two possible causes.
1. The water temperature has become too hot and caused the safety stat to shut off the oil
supply.
2. Oil has entered the safety float chamber thus automatically shutting off the oil supply into
the stove.
If item 1 has caused a shut down you will have to wait for the water temperature to drop before
you will be able to reset the valve.
If item 2 has caused the problem you will have to seek help from your serviceman.
O
O
I
I
L
L
F
F
L
L
O
O
W
W
C
C
O
O
N
N
T
T
R
R
O
O
L
L
K
K
N
N
O
O
B
B
Controls the flow of oil into the pot and can be rotated to adjust the flow of oil from minimum to
maximum or any setting in between, determined by where you set it.
o Fully clockwise turns the appliance off.
W
W
A
A
T
T
E
E
R
R
T
T
E
E
M
M
P
P
E
E
R
R
A
A
T
T
U
U
R
R
E
E
C
C
O
O
N
N
T
T
R
R
O
O
L
L
K
K
N
N
O
O
B
B
Controls the flow of oil but this control is different in as much as it is related to the water
temperature.
o FULLY CLOCKWISE is for low water temperature
o FULLY ANTICLOCKWISE is for high water temperature.
The water-sensing thermostat will automatically control the boiler water temperature at whatever
setting is required.
If the stove is fired up at full output it will run on full flame until it achieves the target water
temperature as set on the stat knob, and then automatically drop the flame onto mini, from there
on it will automatically modulate the flame from high to low in line with the heating load
demand.
