DP12VL
25
PARTS LIST
61 Hex Bolt M8x12 3 90 Bevel Indicator 1
62 Spring Washer D8 3 91 Rack Collar 1
63 Motor Plate 1 92 Table Support 1
64 Flat Washer D8 4 93 Worm Gear 1
65 Hex Nut M8 5 94 Crank Handle 1
66 Damping Pad 4 95 Hex Bolt M12x35 1
67 Spring Pin 6x15 2 96 Spring Washer D12 1
68 Screw M8x8 3 97 Inner Gear 1
69 Head 1 98 Inner Gear Shaft 1
70 Spring Pin 5x13 1 99 Handle 1
71 Quill Set Screw 1 100 Column Clamp 2
72 Tooth Lock Washer D5 2 101 Plistic Handle 1
73 Philips Screw A
ssy M5x8 2 102 Gauge Block 1
74 Pointer 1 103 Shaft Assy 1
75 Philips Screw Assy M4x6 1 104 Column 1
76 Screw M6x12 1 105 Rack 1
77 Laser 2 106 Hex Bolt Assy M10x25 4
78 Inner Hex screw M6x10 6 107 Column Base 1
79 Work Table 1 108 Base 1
80 Switch Box Cover 1 109 Hex Nut M14 1
81 Stop Button 1 110 Bearing 6002RZ 1
82 Table Arm 1 111 Rubber Washer 1
83 Rack Compression Spring
Item Description QTY. Item Description QTY.
1 112 Quill 1
84 Rack Shaft 1 113 Bearing 6204RZ 1
85 R
ack Bushing 1 114 Main Shaft 1
86 Inner Hex screw M8x60 1 115 Chuck Arbor 1
87 Lock Nut M8 1 116 Chuck 1
88 Philips Screw Assy M4x7 2 117 Chuck Key 1
89 Limit Sleeve 1 118 Philips Screw M5x12 1
