24
DP12VL
PARTS LIST
1 Cord Clamping Hook 2 31 Philips Screw M5x12 5
2 Circlip for Shaft φ24 1 32 Power Switch 1
3 Circlip for Shaft φ35 1 33 Lamp/Laser Switch 1
4 Cam 1 34 Philips Screw ST4.2x20 4
5 Screw M8x12 2 35 Philips Screw M5x14 1
6 Bearing 1 36 Cord Clamping Plate 1
7 Elastic Ring, Type A, Ø55 1 37 Cord Bushing 1
8 Spindle Movable Pulley 1 38 Rubber Bushing 2
9 Cogged V-belt 1 39 Wrench 1
10 Spindle Fixed Pulley 1 40 Power Cord 1
11 Flat Key A4*4*64 1 41 Inner Hex Wre
nch S3 1
12 Spindle Sleeve 1 42 Inner Hex Wrench S4 1
13 Bearing 61905 2 43 Wedge Block 1
14 Retainer 1 44 Screw M6x12 4
15 Circlip for Shaft φ25 1 45 Belt Housing Assembly 1
16 Handle Knob 4 46 Sealant Tape 4
17 Handle 3 47 Philips Screw ST2.9x6.5 4
18 Nut M10 1 48 Photoelectric Counter 1
19 Belleville Spring 1 49 Philips Screw Assy M4x20 2
20 Handle Seat 1 50 Counter Base 1
21 Screw M5x10 3 51 Variable Speed
Item Description QTY. Item Description QTY.
Handle 1
2
2 Speed Adjustment Base 1 52 Circlip for Shaft φ14 1
23 Gear Shaft 1 53 Motor Fixed Pulley 1
24 Flat Key A3*3*25 1 54 Motor Movable Pulley 1
25 Hex Nut M12 2 55 Motor Compression Spring 1
26 Coil Spring Assembly 1 56 Spring Base 1
27 Spring Baffle 1 57 Spring Washer 1
28 Bushing 1 58 Motor Assembly 1
29 Digital Display 1 59 Flat Key A4*4*80 1
30 Switch Box 1 60 Hex Screw M8x18 4
To Next Page
