Bugaboo Cameleon Instructions

b
b
c
en
10
other functions
removing the swivel wheels from the holders
a. The swivel wheel has a round button which protrudes through the holder.
The button has 2 sprung lips.
b Push on the 2 lips and remove the swivel wheel from
the holder.
c. Do the same on the other side.
swivel wheels unlocked
a. Push down the swivel locks.
b. The swivel wheels are unlocked.
c. The Bugaboo Cameleon’s maneuverability is highest
with this setting.
swivel wheels locked
a. Push up the swivel locks.
b. The swivel wheels are locked.
c. The Bugaboo Cameleon now moves in a straight line.
adjusting the swivel wheels
The suspension is usually adjusted to the lightest setting.
a. Set the swivel wheels to locked.
b Pull down the white spring clamp.
c Slide the white spring clamp to one of the 4 positions.
d. Fasten the spring on both swivel wheels in the
same position.
Important Push the spring clamp off the frame (if the swivel
wheels are locked). The suspension becomes
tighter. For ongoing optimum comfort,
Bugaboo recommends adjusting the spring one
notch for every 5 kg/11 lbs of load (child + baggage
in the underseat bag).
Important The adjustable suspension of both swivel wheels
should be in the same position to avoid hazardous
situation.
Z54010 - UG_C_rv00.indb 10 12/6/07 12:51:42

Bugaboo Cameleon Specifications

General

Type	Traditional stroller
Foldable	Yes
Washing type	Machine wash
Product color	Aluminium, Khaki
Frame material	Aluminum
Number of seats	1 seat(s)
Wheels material	Foam
Maximum baby weight	17 kg
Recommended age (max)	36 month(s)
Recommended age (min)	6 month(s)
Number of front wheels	2
Stroller accessories included	Rain cover
Wheels mobility	Fixed, Swivel

Weight and Dimensions

Weight	9600 g
Folded depth	900 mm
Folded width	500 mm
Folded height	310 mm
