6. fitting the underseat bag
The underseat bag hangs under the bassinet or seat.
step 1 fitting the under seat bag
The under seat bag is fastened between the wheels of the chassis.
a. Remove the frame from the chassis.
b Fit the under seat bag to the chassis between the
axles of the wheels with the Bugaboo logo facing the
large wheels.
c Attach the 2 touch fasteners to the upper center shaft.
d Attach the other 2 touch fasteners to the
supports of the swivel wheels.
Important The under seat bag is made to carry a maximum
weight of 4 kg/8.8 lbs.
Before use, ensure that all the touch fasteners
are properly attached.
