teners. Fold the seat portion inwards to convert the unit into a seat.
3
Position the O-ring over the projecting pin (see diagram E3 ,red arrow A). This is easiest when the carry
handle is not connected, as the frame can flex slightly. Then position the seat onto the side. Bend the
seat/bassinet frame inwards by pushing on the side of the seat/bassinet frame (see red arrow B). Pull the
ties and position the O-ring over the projecting pin (see red arrow C).
4
Click the ties together under the seat (see diagram E4 , red arrow A). Fasten the two hook & loop fastener
strips at the foot to the underside of the seat/bassinet frame (see red arrow B). Ensure that the hook &
loop fasteners and the ties are properly fastened.
Attaching the sun canopy
The sun canopy attaches to the seat and to the bassinet in the same way. See Diagram C2.
Attaching the carry handle
5
Attach the carry handle to the seat by pressing the small white square buttons and sliding the ends into
the slots until you hear a click on each side.
Removing the carry handle
6
Push down slightly on the carry handle, then press the small square buttons firmly and slide the ends of
the carry handle out of the slots.
WARNING
Always check to ensure that the carry handle is fitted correctly before you
use it to lift the bassinet.
WARNING
Avoid serious injury from falling or sliding out. The occupant restraint sys-
tem is to be used.
WARNING
When locking the carry handle, you must hear a click on each side.
Failure to properly attach the carrying handle could result in the serious
injury or death of your child.
F to use the seat freestanding and on the chassis
Your Bugaboo Frog seat is designed to carry one child who weighs less than 37 pounds. When using
your Bugaboo Frog freestanding, put the backrest in the semi-reclining position. When using the seat on the
chassis, the backrest can be adjusted to sitting, semi-reclining and reclining positions, and the angle between
the backrest and the seat of your Bugaboo Frog seat unit will remain constant. With infants younger than six
months, do not use the seat in the sitting position. Use it only in the reclining and semi-reclining position, and
then for not more than two hours at a time.
Seat used freestanding with backrest in semi-reclining position
1
The seat can only be placed freestanding on the ground when the backrest is in the semi-reclining posi-
tion. To set this position, open out the seat adaptors completely backwards.
Attaching the seat to the chassis
Slide the side brackets of the seat onto the lugs sticking up from the chassis until you hear a click on both
sides, in the same way as with the bassinet. See Diagram D1.
Changing the position of the seat after attaching it to the chassis
2
To change position, press the round buttons on the side brackets and tilt the seat as desired.
Removing the seat from the chassis
To remove the seat from the chassis, press the large white square buttons on each side of the seat at the
same time, then lift it by the carry handle. See Diagram D2.
Reversing the seat
The seat will fit the chassis facing either way. To reverse it, remove it from the chassis, turn it around, and rein-
sert it until you hear a click on both sides. (See Diagrams D3 and D4.) The sitting, reclining and
semi-reclining positions can be set with the seat facing either way.
6
