Product use
Installation concerns
This infant carrier module is suitable for vehicle seats
with i-Size ISOFIX anchor points with the Base.
(1)
DO NOT use the rearward facing enhanced child
restraint systems in seating positions where there is
an active frontal airbag installed. Death or serious
injury may occur. (2) Please reference vehicle owner’s
manual for more information.
DO NOT install this enhanced child restraint on vehicle
seats that face sideways or rearward with respect to
the moving direction of the vehicle. (3)
It is recommended to install this enhanced child
restraint on the rear vehicle seat. (4)
DO NOT install this enhanced child restraint on
vehicle seats movable during installation.
Handle adjustment
1 The handle of the infant carrier module can be
adjusted to 3 positions. (5)
Baby chair position. (5)-1
Position for placing the baby in the seat. (5)-2
Position for car, hand or stroller transportation.
(5)-3
2 To adjust the handle, squeeze handle buttons on
both sides to release it. (6)-1
3 Rotate handle until it clicks into any of the 3
positions. (6)-2
Installation with base
1 Unfold the load leg from storage compartment. (7)
2 Fit the ISOFIX guides with the ISOFIX anchor
points. (8) The ISOFIX guides can protect the
surface of the vehicle seat from being torn. They
can also guide the ISOFIX connectors.
3 Press the ISOFIX Adjust Button to adjust the
ISOFIX connectors. (9)
4 Line up the ISOFIX connectors with the ISOFIX
guides, and then click both ISOFIX connectors
into the ISOFIX anchor points. (10)
Make sure that both ISOFIX connectors are
securely attached to their ISOFIX anchor points.
There should be two audible clicks and the colors
of the indicators on the both ISOFIX connectors
should be completely green. (10)-1
Check to make sure the base is securely installed
by pulling on the both ISOFIX connectors.
5 After placing the base on the vehicle seat,
extend the load leg to oor (11). When the load
leg indicator shows green means it is installed
correctly, red means it is installed incorrectly.
(11)-2
The load leg has 19 positions. When the load leg
indicator shows red this means the load leg is in
the wrong position.
Make sure the load leg is in full contact with the
vehicle oor pan.
14 15
