Buhler 2895 - Hydraulic Fitting and Torque Specifications; Hydraulic Fitting Torques; Prevailing Torque Locknut Torques

bühler
Allied Front-End Loader
- 42 - P4110
Hydraulic Fitting Torques:
(ft-lbs) (NM) (ft-lbs) (NM)
-04 7/16-20
14-16 20-22 10-11 13-15
-05 1/2-20
18-20 24-27 13-15 18-20
-06 9/16-18
24-26 33-35 17-19 23-26
-08 3/4-16
50-60 68-78 34-38 47-52
-10 7/8-14
72-80 98-110 50-56 69-76
-12 1-1/16-12
125-135 170-183 70-78 96-106
-14 1-3/16-12
160-180 215-245 80-90 110-122
-16 1-5/16-12
200-220 270-300 94-104 127-141
-20 1-5/8-12
210-280 285-380 124-138 169-188
-24 1-7/8-12
270-360 370-490 156-173 212-235
Dash Size
Thread
Size
Jam Nut or Straight SAE 37° (JIC)
ORB Fitting Torque Swivel Nut Torque
Prevailing Torque Locknuts:
(ft-lbs) (NM) (ft-lbs) (NM)
0.250-20
5-7 7-9 7-10 9-14
0.313-18
9-12.5 12-17 11-16 15-22
0.375-16
14.5-20 20-27 20-28 27-38
0.438-14
23-32 31-43 31-43 42-58
0.500-13
37-50 50-68 45-62.5 61-85
0.563-12
50-70 68-95 70-95 95-129
0.625-11
70-95 95-129 90-122.5 122-166
0.750-10
125-165 169-224 155-210 210-285
0.875-9
185-250 251-339 225-312.5 305-423
1.000-8
275-375 373-508 360-462.5 488-627
0.250-28
5.5-7.5 7-10 7-10 9-14
0.313-24
10-13 14-18 12-17 16-23
0.375-24
16-22 22-30 21-29 28-39
0.438-20
24-34 33-46 31-43 42-58
0.500-20
37.5-52.5 51-71 50-70 68-95
0.563-18
57.5-77.5 78-105 70-95 95-129
0.625-18
72.5-97.5 98-132 90-125 122-169
0.750-16
120-165 163-224 155-210 210-285
0.875-14
200-270 271-366 225-312.5 305-423
1.000-14
300-400 407-542 362.5-500 491-678
Coarse Thread
Fine Thread
Nut Size
and
Threads
Grade B Nuts Grade C Nuts
Nut Tightening Torque Nut Tightening Torque
Notes:
1) For Grade A locknut torque specifications refer to Grade B specifications.
