6-64
Fuse Description
ABS Anti
-Lock Brakes
TURN SIGNALS,
CORN LPS
Turn Signals, Cornering Lamps
RADIO, HVAC,
RFA, CLUSTER
Radio, HVAC Head, Remote
Keyless Entry, Cluster
HIGH BLOWER High Blower
RH HEATED
SEAT
Passenger’s Heated Seat
STRG WHL
CONT
Audio Steering Wheel Controls
WIPER Wipers
Underhood Electrical Center
-- Passenger’s Side
Some fuses and relays are located in the underhood
electrical center on the passenger’s side of the
engine compartment.
Maxi fuse Description
1 ABS
2 Starter Solenoid
3 Power Seats, Rear Defog,
Heated Seats
4 High Blower, Hazard Flasher,
Stoplamps, Power Mirror, Door Locks
