6-65
Maxibreaker Usage
41 Starter
MaxiFuses Usage
42 A.I.R.
43 ABS
44 Air Pump B
45 Air Pump A
46 Cooling Fan 2
47 Cooling Fan 1
Spare Fuses Usage
48 Spare
49 Not Used
50 Not Used
51 Not Used
52 Not Used
53 Fuse Puller
Removing the Rear Seat Cushion
NOTICE:
The battery and main fuse blocks are located
under the rear seat cushion. The battery’s
ground terminal and some relay wires are
exposed. To help avoid damage to the battery
and wires, be careful when removing or
reinstalling the seat cushion. Do not remove
covers from covered parts. Do not store anything
under the seat, as objects could touch exposed
wires and cause a short.
To remove the rear seat cushion:
1. Pull up on the front of the cushion to release the
front hooks.
2. Pull the cushion up and out toward the front of
the vehicle.
