Capacities and Specifications
Engine VIN Code Transmission Spark Plug Gap
“VORTEC™ ” 4200 L6 S M30 0.042 inches (1.07 mm)
“VORTEC™ ” 5300 V8 P M30 0.040 inches (1.01 mm)
Application
L6 Engine V8 Engine
English Metric English Metric
Wheel Nut Torque 100 lb ft 140 Y 100 lb ft 140 Y
Cooling System 13.9 quarts 13.1 L 15.3 quarts 14.5 L
Air Conditioning Refrigerant R/134a 1.9 lbs. 0.85 kg 1.9 lbs. 0.85 kg
Engine Oil with Filter 7.0 quarts 6.6 L 6.0 quarts 5.7 L
Transmission
(Drain and Refill)
5.0 quarts 4.7 L 5.0 quarts 4.7 L
Differential Fluid
Rear 3.6 pints 1.7 L 4.3 pints 2.0 L
Front 1.7 pints 0.8 L 1.7 pints 0.8 L
Fuel Tank 22.0 gallons 83.3 L 22.0 gallons 83.3 L
All capacities are approximate. When adding, be sure to fill to the appropriate level, as recommended in this manual.
Recheck the fluid level after filling.
5-113
