Vehicle Care 10-39
Fuse
Number
Usage
71 Not Used
Relay
Number
Usage
1 Air Conditioning
Control
2 Starter
3 Not Used
4 Front Wiper (Step 2)
5 Front Wiper (Step 1,
Interval)
6 Right Low Beam
Headlamp/DRL
7 Main Relay
8 Auxiliary Heater
Pump (eAssist Only)
9 Cooling Fan
10 Cooling Fan
Relay
Number
Usage
11 Transmission
Auxiliary Pump
(eAssist Only)
12 Not Used
13 Cooling Fan
14 High Intensity
Discharge
Headlamp/Left Low
Beam
Headlamp/DRL
15 Ignition
16 Secondary AIR
Pump (eAssist Only)
17 Window/Mirror
Defog
Instrument Panel Fuse
Block
The instrument panel fuse block is
located in the instrument panel, on
the driver side of the vehicle.
To access the fuses, open the
storage compartment. Press in on
the sides of the compartment to
release it from the instrument panel.
Pull the door toward you to release
it from the hinge.
