Page 13
MASTER ON/OFF SWITCH(S)
The master ON/OFF switch disables power the entire brewer (including tank heaters).
NOTE – TWINS with 2 power cords will have 2 power switches, (one left, one right).
TANK HEATER ON/OFF SWITCH(S)
The tank heater ON/OFF switch disables power to the tank heater circuits only. Power to brew timer and warm-
er circuits are not affected. All Twins have 2 tank heater switches. NOTE: Leaving the tank heater switch(s) off
will result in brewing with cold water.
EARLY MODEL SWITCHS
LATE MODEL SWITCHS
FIGURE 13-1 FIGURE 13-2
FIGURE 13-3 FIGURE 13-4
OPERATING CONTROLS
41721 111308
