Bunn CWT-CS - Page 19

ITEM PART NO. QTY. DESCRIPTION
19
1 12921.0000 1 Switch Blank, BLK
2 12920.0000 4 Switch ON/OFF 120V (One less used on brewers w/out top warmer)
3 01063.0000 1 Switch, Momentary Start
4 22295.0013 1 Label, Switch ON/OFF (Three lower warmer brewer)
5 22295.0014 1 Label, Switch ON/OFF (Four warmer brewer)
6 04243.0000 2 Terminal Housing, Receptacle
7 13352.0008 1 Control Panel
02301.0000 4 Screw, Phillip Pan Head #6-32 x .625”
01510.0000 4 Lockwasher, External Tooth #6
02371.0000 4 Thumb Nut, Knurled #6-32
8 22289.0001 1 Decal, Control Panel
9 12984.0002 1 Light Assembly, 120V Green
12984.0004 1 Light Assembly, 240V Green
10 01663.0000 1 Bushing, Snap .875” Dia
11 02235.1000 1 Timer, 5 Min. 120V
02308.0000 1 Screw, Pan Head-Serrated #8-32 x .375”
12 04227.1001 1 Thermostat Kit
02308.0000 1 Screw, Pan Head #8-32 x .375”
13 12698.0000 1 Bracket Assembly, Component Mounting
01347.0000 1 Screw, Truss Head #6-32 x .375” (Early Models)
02308.0000 1 Screw, Pan Head #8-32 x .375” (Late Models)
02332.0001 1 Screw, Hex-Crimptite #6 x .250”
14 00870.0000 1 Decal, Use Copper Wire Only
15 07038.0000 1 Terminal Block, 3 Pole-Red/White/Black
01317.0000 2 Screw, Truss Head #8-32 x .50”
16 07073.0000 1 Grommet, Thermostat
17 23697.0000 1 Facenut, Plastic
18 23696.0000 1 Nut, Hex
19 25102.0000 1 Bracket, Switch Indicator/Guard
20 23522.0000 1 Switch, ON/OFF Toggle (Includes item 18)
21 01686.0000 1 Bushing, Strain Relief (Mode l15 Brewers)
22 01685.0000 1 Connector, Cable .50 MPT (Model 20 & 35 Brewers)
23 01719.0000 1 Power Cord Assembly (Model 15 Brewers Only)
24 12985.0000 1 Wiring Harness, Ready Light
25 25328.0000 1 Wiring Harness, Main 120V
25329.0000 1 Wiring Harness, Main 120V/240V
26 12919.0000 - Cap, Terminal (Use as required)
27 02337.0001 1 Screw, Hex Head #10 x .375” (Cord Ground)
ELECTRICAL AND OPERATING CONTROLS W/OUT FAUCET
Not Illustrated
Includes Item 6
26492 122101
