Bunn VPR Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
19
* Indicates the part number listed is obsolete with no replacement.
* VPR - VPRA
** VPS - VPSA
* **
1 03625.0000* 2 3 Warmer Assembly, Brn 100W 120V
03652.0000 2 3 Warmer Assembly, Blk 100W 120V
01973.0000* 2 3 Warmer Assembly, Brn 100W 220V
02817.0000 2 3 Warmer Assembly, Blk 100W 220V
01303.0000 6 9 Screw, Pan Head #4-40 x .50”
00916.0000 6 9 Fastener, J-Type
2 03655.0000* 1 1 Warmer Dish, Brn
03656.0000 1 1 Warmer Dish, Blk
3 01227.0000 1 1 Warmer Element, 100W 120V (Shown)
01951.0000 1 1 Warmer Element, 100W 220V (Not illustrated)
4 13042.0001 1 1 Spacer, .174” I.D. .188” (120V Warmers only)
5 05212.0000 1 1 Plate, Warmer Retainer
00970.0000 2 2 Nut, Keps #8-32
6 04226.0000* 2 3 Lamp, Brn 125V
04226.0002 2 3 Lamp, Blk 125V
01089.0001 2 3 Lamp, Blk 240V (Prior to 1/3/97 on “A” models only)
27691.0000 2 3 Lamp, Blk 240V (Effective 1/3/97 on “A” models only)
7 04225.0000* 2 3 Switch, On/Off Toggle - Brn
04225.0002 2 3 Switch, On/Off Toggle - Blk
01186.0000 2 3 Switch, On/Off Toggle (Prior to 1/3/97)
27689.0000 2 3 Switch, On/Off Toggle (Effective 1/3/97)
8 01905.0000 1 1 Lamp, Power-On 220V (Prior to 1/3/97) (Round)
27691.0000 1 1 Lamp, Power-On 220V (Effective 1/3/97) (Rect)
9 01908.0000 1 1 Power Connector, 10A 250V
01362.0000 2 2 Screw, Oval Head #4-40 x .50”
01509.0000 2 2 Lock washer, External Tooth, # 4
00937.0000 2 2 Nut, Hex #4-40
10 - - - - - - - - 1 1 Lead, Ground Grn/Yel (Not Available)
01375.0000 1 1 Pan Head (Brass) #10-32 x .50”
01512.0000 1 1 Lock washer, External Tooth #10
11 00824.0000 1 1 Decal, Ground
12 01667.0000 8 12 Terminal, .25”
Note: The following items are not illustrated
13 21016.0011 1 1 Lead, Ground - Grn/Yel (Upper Warmer)
21016.0012 1 2 Lead, Ground - Grn/Yel (Lower Warmer)
14 01637.0000 1 1 Cord Assembly, Power (VPR, VPS)
01311.0000 1 1 Screw, Truss Head #8-32 x .25”
01511.0000 1 1 Lock washer, External Tooth #8
00970.0000 1 1 Nut, Keps #8-32
01716.0000 1 1 Cord Assembly, Power (VPRA, VPSA)
02337.0000 1 1 Screw, Zinc Pltd. “AB” #10-32 x .38”
ELECTRICAL AND OPERATING CONTROLS
Includes Items 2 thru 5
“A” models only
(Continued)
10784 121206

Bunn VPR Specifications

General

Type	Coffee
Product type	Drip coffee maker
Capacity in cups	12 cups
Water tank capacity	14.4 L
AC input voltage	120 V
