Burley Encore Owner’s Instruction and Safety Manual
X. Parts List and Drawing
Note: Subassemblies are indented. Inquire for additional parts.
1 (1) Preassembled Main Frame Assembly
2 (1) Front Main Frame, 1" Aluminum Tube
3 (1) Rear Main Frame, 1" Aluminum Tube
4 (1) Left Inner Frame, 1" Aluminum Tube
5 (1) Right Inner Frame, 1" Aluminum Tube
6 (1) Bag Holder, 3/4" Alu mi num Tube
7 (4) Wheel Dropout
8 (1) Roll Bar Assembly
9 (1) Roll Bar Receptacle, Plastic
10 (1) Roll Bar Hinge, Plastic
11 (1) Tongue and Hitch Assembly
12 (1) Tongue, 1 1/8" Alu mi num Tube, Spindle, Washer,
(2) Tongue Hangers, Locknuts
13 (1) Hitch w/Hitch Knob & Ball
14 (1) Hitch Safety Strap
15 (1) Clip & D-Ring
16 (1) Rubber Flex Connector
17 (1) Tongue Receptacle, Plastic & front Refl ector Bracket (left and right)
18 (2) Side Rail, 3/4" Aluminum Tube
19 (2) Pair Side Rail Hinges, Per Side Rail
20 (10) Side Rail Snap Studs
21 (1) Fabric Bottom Bag and Side Panel Assembly w/Vinyl
Win dows & Side Pocket
22 (2) Wooden Side-panel Battens
23 (1) Fabric Child Seat with Harness
24 (1) Buckle for Lap Belt
(2) Wheels w/Quick-Release Hubs (not shown)
25 (1) 2-Piece Safety Flag
(1) Hardware Bag containing:
26 (2) Front Refl ector w/Self-Tapping Screw
27 (2) Rear Refl ector w/Self-Tapping Screw
(2) Wheel Quick-Release Levers (not shown)
(2) Wheel Refl ectors, (4) bolts, (4) nuts and (8) washers (not shown)
28 (1) 2-in-1 Cover
29 (2) Handle Receivers
30 (1) Handle
Options (at additional cost):
Walk ’n Roller stroller kit (not shown)
