BURLEY STROLLER KIT OWNER’S INSTRUCTION AND SAFETY MANUAL
5. Around handlebar center, slide tether strap end through small
loop on other end of strap and tighten securely. Photo 1
6. Slide tow bar into trailer receptacles and line up front
tow bar hole with rear receptacle hole. Insert retaining pin
through both holes and lock retaining hoop securely. Figure 5
7. Test tracking adjustment by pushing trailer. Trailer should
roll straight.
To Adjust Tracking
1. Tighten knob to secure stroller wheel in “Stroll” position.
See Figure 6
2. Loosen bolt using 5mm hex wrench. Figure 6
3. Turn bushing using 25 mm (or 1”) wrench so that stroller
wheel is vertical when viewed from front.
4. Fine tune as necessary, so that trailer rolls straight.
5. Tighten bolt.
Figure 6
Photo 1
