Thank you for purchasing your new
WARNING: As with any laser device, it is not recommended to directly view the emissions for long
periods of time with magni ed lenses.
INTRODUCTION
*Note: You will get both longer and shorter maximum distances depending on the refl ective properties of the particular target
and the environmental conditions at the time the distance of an object is being measured. The color, surface fi nish, size and
shape of the target all affect refl ectivity and range. The brighter the color, the longer the range. White is highly refl ective, for
example, and allows longer ranges than the color black, which is the least refl ective color. A shiny fi nish provides more range
than a dull one. A small target is more diffi cult to range than a larger target. The angle to the target also has an effect. Shooting
to a target at a 90 degree angle (where the target surface is perpendicular to the fl ight path of the emitted energy pulses)
provides good range while a steep angle on the other hand, provides limited ranging. In addition, lighting conditions (e.g.
the amount of sunlight) will affect the ranging capabilities of the unit. The less light (e.g. overcast skies) the farther the unit’s
maximum range will be. Conversely, very sunny days will decrease the unit’s maximum range.
HOW OUR DIGITAL TECHNOLOGY WORKS
BATTERY ACTIVATION / BATTERY LIFE INDICATOR
Before first use:
NOTE: It is recommended that
the CR2 3-volt lithium battery be replaced at least once every 12 months. Insert it into the
compartment negative end first.
ENGLISH
PARTS GUIDE
MONOCULAR EYEPIECE
BATTERY COMPARTMENT
COVER
STRAP LUG
POWER/FIRE BUTTON
LASER TRANSMIT/RECEIVE
LENSES
MONOCULAR OBJECTIVE LENS
MODE BUTTON
