Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Parts List
Hand Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-448-2142
E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com
(*) - Indicates items included in, and available only as part of Repair Kit. Repair Kits require special skill, training and
equipment to repair. Installation must be done by Authorized Service Center. Contact BVA for list of Authorized
Service Centers.
N/A - Part is not available as replacement.
11
MODEL: H18-4-1600-909, P1000 Base Assembly
Item Part Number
Description
Qty
1 H18-6-1322-101 Hook Base 1
2 * Washer 1
3 649-1-0050-037 Screw 1
4 N/A Base 1
5 * O-ring 1
6 * Back-up Ring 1
7 H28-4-4406-108 Piston Ass. 1
8 644-1-0060-071 Screw 1
9 * Back-up Ring 1
10 * O-ring 1
11 H18-6-2114-200 Fixing Pillar 1
12 651-1-0050-103 Screw 3
13 H18-5-1602-101 Base Plate 1
14 D05-6-1001-106 Nut 1
15 H18-6-1321-200 Hook 1
16 532-8-0050-024 Filter 1
Item Part Number
Description
Qty
17 H18-4-1901-105 High Pressure Valve Ass. 1
18 * O-ring 1
19 H18-4-1603-107 Release Valve 1
20 H18-6-1308-107 Iron Plate 1
21 649-1-0050-028 Bolt 1
22 601-7-0008-009 Steel Ball 3
23 552-2-0061-102 Bevel Compressing Spring 2
24 601-7-0012-000 Steel Ball 2
25 552-2-0080-106 Bevel Compressing Spring 2
26 H18-6-1215-100 Nut 2
27 * Special Washer 2
28 H18-4-1902-208 Low Pressure Valve Ass. 1
29 512-2-0060-016 Compressing Spring 1
30 661-2-0040-012 Nylon Frange Nut 1
* H18-3-9912-104 Repair Kit - P1000 1
To Next Page
