Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Parts List
Hand Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-448-2142
E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com
(*) - Indicates items included in, and available only as part of Repair Kit. Repair Kits require special skill, training and
equipment to repair. Installation must be done by Authorized Service Center. Contact BVA for list of Authorized
Service Centers.
N/A - Part is not available as replacement.
13
MODEL: P1000AD
Item Part Number Description Qty
1 H18-4-1903-109
Base Assy., Please
see page #14 & #15
for the detail
1
2 H18-6-1908-101 Steel Tube 1
3 H18-5-4401-207 Steel Bar 1
4 H18-6-1910-108 Silcon Tube 1
5 * O-ring 1
6 H18-6-1907-109 Silcon Tube Seat 1
7 532-8-0040-012 Filter 1
8 H18-6-1909-103 Sucking Tube 1
9 H18-5-1502-208 Support Plate 1
10 651-1-0050-103 Screw 2
11 671-2-0100-205 Nut 1
12 H18-4-1905-103 Air Vent Assy. 1
13 H18-6-1904-103 Supporting Base 1
14 * Washer 1
15 H18-6-1911-100 Tube 1
16 605-3-0080-102 Spring Washer 2
17 661-2-0080-014 Nut 2
18 677-5-0040-102 E-clip 2
19 H18-5-1318-104 Pin 1
20 H28-6-1823-101 Pin 1
21 H28-6-1824-204 Pin 1
22 H18-3-2100-100 Handle 1
23 H18-6-2112-105 Handle Grip 1
24 D05-6-1001-106 Nut 1
* H18-3-9918-106 Repair Kit 1
