15
Parts Illustration
Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Hand Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-448-2142
E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com
Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized
Replacement Parts only.
MODEL: H18-4-1903-109, P1000AD Base Assembly
Item Part Number Description Qty
1 H18-6-1321-200 Hook 1
2 H18-6-1322-101 Hook Base 1
3 H18-6-1906-107 Air Vent 1
4 * O-ring 1
5 649-1-0050-037 Screw 1
6 512-2-0067-010 Safety Spring 1
7 A17-5-1603-300 Adjustment Screw 2
8 651-7-0004-107
Copper Connector
Assy.
1
9 A17-6-1216-102 Neddle 2
10 * Washer 1
11 641-1-0098-103 Screw 1
12 609-1-0075-105 Pipe Plue 1
13 H18-5-1602-101 Base Plate 1
14 N/A Base 1
15 H28-4-4406-108 Piston Ass. 1
16 * O-ring 1
17 * Back-up Ring 1
Item Part Number Description Qty
18 H18-6-2114-200 Fixing Pillar 1
19 644-1-0060-071 Screw 1
20 * Back-up Ring 1
21 * O-ring 1
22 512-2-0080-306 Compressing Spring 1
23 H18-6-1215-100 Nut 2
24 * Special Washer 2
25 601-7-0008-009 Steel Ball 3
26 552-2-0061-102
Bevel Compressing
Spring
2
27 601-7-0012-000 Steel Ball 2
28 552-2-0080-106
Bevel Compressing
Spring
2
29 651-1-0050-103 Screw 3
30 H28-4-1700-105 Release Valve 1
31 512-2-0060-016 Compressing Spring 1
32 661-2-0040-012 Nylon Frange Nut 1
* H18-3-9918-106 Repair Kit - P1000AD 1
To Next Page
