Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Parts List
Hand Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-448-2142
E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com
(*) - Indicates items included in, and available only as part of Repair Kit. Repair Kits require special skill, training and
equipment to repair. Installation must be done by Authorized Service Center. Contact BVA for list of Authorized
Service Centers.
(**) - Indicates item is included in the H39-3-9920-106 Handle Hardware Kit
(***) - Indicates item is included in the H39-3-9930-109 Pressure Valve Repair Kit
N/A - Part is not available as replacement.
7
MODEL: P350
Item Part Number Description Qty
1 N/A Base 1
2 H39-6-2108-208 Fixing Pillar 1
3 H39-6-2109-109 Fixing Ring 1
4 644-1-0060-05311 Screw 1
5 H39-5-8104-103 Nut 1
6 *** Steel Ball 3
7 * O-ring 1
8 H18-4-1603-107 Release Valve 1
9 H39-6-1308-100 Iron plate 1
10 649-1-0050-028 Screw 1
11 H39-6-1603-102 Base Plate 1
12 651-1-0050-103 Screw 5
13 532-8-0040-012 Filter 1
14 H18-4-1902-208 Low Pressure Valve Assy. 1
15 H18-4-1901-105 High Pressure Valve Assy. 1
16 * Washer 2
17 H39-6-4401-105 Screw Bar 1
18 * O-ring 1
19 H39-6-1502-207 Support Plate 1
20 671-2-0100-205 Nut 1
21 H39-6-2112-108 Gable 1
Item Part Number Description Qty
22 H18-4-1905-103 Air Vent Assy. 1
23 H39-6-1803-302 Tube 1
24 */*** Nut 2
25 */*** Special Washer 2
26 */*** Bevel Compressing
Spring
2
27 */*** Steel Ball 2
28 */*** Bevel Compressing
Spring
2
29 * Back-up Ring 1
30 * O-ring 1
31 H39-4-1606-207 Piston Assy. 1
32 ** E-clip 1
33 ** E-clip 2
34 ** Pin 1
35 ** Pin 1
36 ** Pin 1
37 H39-3-2100-204 Handle 1
38 H18-6-2112-105 Handle Grip 1
* H39-3-9902-104 Repair Kit 1
** - - 1
*** - - 1
To Next Page
