Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Parts List
Hand Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-448-2142
E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com
(*) - Indicates items included in, and available only as part of Repair Kit. Repair Kits require special skill, training and
equipment to repair. Installation must be done by Authorized Service Center. Contact BVA for list of Authorized
Service Centers.
N/A - Part is not available as replacement.
9
MODEL: P1000
Item Part Number
Description
Qty
1
H18-4-1600-909
Base Assy., Please see
page #10 & #11 for the
detail
1
2
H18-5-4401-207 Steel Bar 1
3
* O-ring 1
4
H18-5-1502-208 Support Plate 1
5
651-1-0050-103 Screw 2
6
532-3-0180-100 Special Washer 1
7
671-2-0100-205 Nut 1
8
H18-4-1905-103 Air Vent Assy. 1
9
H18-6-2122-105 Supporting Base 1
10
* Washer 1
11
H18-6-1911-100 Tube 1
12
605-3-0080-102 Spring Washer 2
13
661-2-0080-014 Nut 2
14
677-5-0040-102 E-clip 2
15 H18-5-1318-104
Pin 1
16
H28-6-1823-101 Pin 1
17 H28-6-1824-204
Pin 1
18
H18-3-2100-100 Handle 1
19
H18-6-2112-105 Handle Grip 1
*
H18-3-9912-104 Repair Kit for P1000 1
To Next Page
