Important Safety Notice
Aspects of the installation and commissioning of the PQSensor™ involve working on equip-
ment where errors in installation or failure to follow appropriate safety procedures could result
in exposure of personnel to Lethal High Voltages.
Installation of the PQSensor™ should only be performed by personnel with the necessary
knowledge and training.
Pay particular attention to the safety aspects of those sections of the manual marked with the
symbol.
Ensure that the CVT input is solidly earthed at all times when any installation work is being car-
ried out.
Never open the CVT secondary terminal box unless the CVT is solidly earthed.
Always ensure the bottom end of C
2
and the EMU are solidly earthed before energising the
CVT.
The nominal output signal from the PQSensor™ is 63.5V. This can be present at any time that
the PQSensor™ is energised.
