Installation Manual

Table of Contents

Questions and Answers

  • W
    William RobertsonAug 5, 2025
    What to do if the Tank Full light is illuminated on my BW SOLAR Water Pump?
    • A
      Alyssa ReynoldsAug 5, 2025
      If the Tank Full light is illuminated, there might be several reasons. First, check the remote switch connections and tank volume. Second, inspect the entire length of the cable for any damage. Third, ensure there are no stray wires or insects creating a short at terminals COM2 and TH. Finally, examine the pressure gauge for blockages and remove any dirt from the inlet at the bottom.
  • S
    Shawna McphersonAug 11, 2025
    What to do if the Low Power light is illuminated on my BW SOLAR Waterboy Water Pump?
    • J
      Johnathan Barnes IIIAug 11, 2025
      If the Low Power light is illuminated, it could be due to a few reasons. It might be that the sunlight isn't strong enough, so wait until the sunlight level increases, or remove any objects shading the array. Also, check all connections between the panels and to the controller for any looseness, and replace any damaged panels. Finally, inspect the pump cable splice connection and repair or replace it if needed. It also may be that the pump is water locked or blocked.
  • B
    Benjamin RamirezAug 19, 2025
    What to do if the ERR I light is illuminated on my BW SOLAR Water Pump?
    • C
      Caleb SandersAug 19, 2025
      If the ERR I light is illuminated, it could be due to several reasons. First, ensure you are using a power cable larger than 4mm2. If not, use a heavier duty power cable. Second, check for and remove any debris blocking the motor or pump. Lastly, make sure the pump is not submerged too deep; raise the pump to within 30m of the maximum water level.
  • B
    Brian MillerAug 27, 2025
    What to do if the Well Low light is illuminated on my BW SOLAR Waterboy?
    • K
      Kayla DavidsonAug 27, 2025
      If the Well Low light is illuminated, it may be because the water level is too low, and the sensor has turned off the pump. In this case, wait for the water level to recover in the source. Alternatively, if no low water level sensor is installed, install one according to the instruction manual. If no sensor is required, install a jumper wire between COM1 and WH.

Summary

INTRODUCTION

Information and Limitations

Key information and limitations before installing the pump system.

Corrosive Water

Information on handling corrosive water and its effect on pump parts.

INSTALLATION

Bore Installation

Steps for installing the pump in a bore or well, including safety cable use.

Dam Installation

Instructions for installing the pump in a dam, including probe placement.

Other Water Sources

Guidance for installing the pump in alternative water sources like lakes or rivers.

Windmill;Hand Pump Cylinder Integration

How to combine WATERBOY pumps with windmills or hand pumps.

Siphon Application Warning

Warning about siphon effects and prevention methods to avoid motor damage.

SOLAR ARRAY

Seasonal Adjustment

How to adjust the solar array angle for optimal output based on seasons.

Array Wiring

Explains series and parallel wiring configurations for solar panels.

Lightning Protection

Recommendations for lightning protection for the pump system.

Float Switch Cable Protection

Best practices for using shielded cable for float switch connections to prevent surges.

CABLE JOINING

Splicing Pump Motor Cable

Detailed steps for splicing the submersible pump cable to the motor.

Splicing Low Water Probe Cable

Instructions for splicing the submersible cable to the low water probe.

CONNECTING THE CONTROLLER

Controller Wiring Steps

Step-by-step guide for wiring the Waterboy MPPT Solar Pump Controller.

Speed and Timer Adjustments

How to adjust pump speed and timer settings for optimal operation.

ELECTRICAL CONNECTIONS

Controller Wiring Diagram

Visual diagram and notes for controller wiring, including probe connections.

Solar Module Series Wiring

Diagram illustrating how to wire solar modules in series.

Solar Module Series;Parallel Wiring

Diagrams for wiring solar modules in series/parallel configurations.

REMOTE SWITCHING

Tank Float Switch

Description, installation, and wiring of the Waterboy Tank Float Switch.

Pressure Switch Wiring

Wiring instructions for the Waterboy Pressure Switch to the controller.

Pressure Switch Setting

How to set the operating pressure for the Waterboy Pressure Switch.

TROUBLESHOOTING

Controller Indicators

Explanation of controller LED indicators and what they signify.

Troubleshooting Common Complications

Checklist and steps to diagnose common pump issues and complications.

MAINTENANCE

Component Maintenance Overview

Maintenance for controller, motor, pump end, solar array, and wiring.

Specific Maintenance Issues

Addressing water lock, sun exposure, cleaning, and power wiring.

Pump Rotor and Stator Replacement

Procedure for replacing the pump rotor and stator, including dismantling and fitting.

Parts Inspection

How to inspect the rotor and stator for wear and scoring.

NOTES

WARRANTY STATEMENT

Warranty Terms and Conditions

Details on warranty limitations, performance, costs, agent responsibilities, and validity.
