USER MANUAL

www.bxterra.com

BM1500AVRLCD| BM1350AVRLCD

BM1000AVRLCD | BM850AVRLCD

BM INTELLIGENT LCD UPS

Table of Contents

Questions and Answers:

J
Joshua WellsAug 4, 2025
Why is my bXterra BM1500AVRLCD battery backup time too short?
- K
  Kimberly HolmesAug 4, 2025
  There are several reasons why your bXterra UPS battery backup time might be too short. It could be due to low battery voltage, in which case you should charge the battery for at least 6 hours. Another cause might be an overload; try unplugging some noncritical devices and verify that the load matches the UPS capabilities. If neither of these resolves the issue, the battery may be defective.
R
rebecca70Aug 11, 2025
What to do if the circuit breaker button is projecting from the back of my bXterra BM1500AVRLCD unit?
- S
  Stephanie NortonAug 11, 2025
  If the circuit breaker button is projecting, it means the circuit breaker has tripped due to an overload. To fix this, turn the bXterra UPS off and unplug one piece of equipment. Wait 10 seconds, then reset the circuit breaker and turn the UPS on again.
K
Karen VazquezAug 18, 2025
Why is my bXterra UPS always on Battery Mode?
- C
  Cynthia AndersonAug 18, 2025
  If your bXterra UPS is always on Battery Mode, the power cord may be loose. Check that the power cord is plugged in properly.

bXterra BM1500AVRLCD Specifications

General

Category	UPS
Capacity	1500VA
Output Power	900W
Nominal Output Voltage	120V
Nominal Input Voltage	120V
Input connection type	NEMA 5-15P
Battery Type	Sealed Lead Acid
Topology	Line Interactive
Waveform type	Simulated Sine Wave
Audible Alarm	Yes
LCD status display	Yes
Display	LCD
Communication Interface	USB
Operating Temperature	0 - 40°C
Form Factor	Tower
Output Voltage	120 VAC
Input Frequency	50/60Hz
Transfer Time	4-8ms
Battery Recharge Time	6 Hour
Data line protection	RJ-45
Protection	Overload, Short Circuit
Operating Humidity	0 - 95%

Summary

Safety Instructions

General Installation and Environment Safety

Covers intended use, controlled environment, hazardous voltage, and servicing restrictions.

Electrical and Placement Safety

Includes grounding, circuit protection, plug modifications, extension cords, placement, and temperature.

Safety Instructions Continued

Generator and Outlet Safety

Transportation and Battery Warnings

Avoid transportation use; batteries pose shock/burn risks; no user-serviceable parts.

Installation and Operation

Product Overview and AVR

Connecting and Powering the UPS

Covers connecting to utility power, charging, determining power requirements, and turning the UPS on/off.

Outlet Usage and Protection

Explains battery backup outlets, surge-protected outlets, and modem/phone line protection.

Equipment and Software Setup

Battery Replacement

Safety Precautions for Battery Handling

Essential safety measures, including personal protection and tool usage for battery work.

Battery Replacement Steps

Detailed procedure for safely removing and installing the UPS battery.

LCD Display

UPS Operating Modes and Information

Alarm and Mute Functions

Fault Codes

Understanding UPS Fault Indicators

Troubleshooting

Diagnosing and Resolving UPS Issues

Offers solutions for problems like no display, battery mode issues, and short runtime.

Technical Specifications

UPS Electrical and Output Parameters

Battery and Protection Features
