ITEM NO. PART NO. DESC RIPTION ITEM NO. PART NO. DESC RIPTION
1 66-104 Nozzle Body 19 61-1003 Air Valve Spring
2 66-105 Seat 20 66-130 Needle Seal Cartridge**
3 66-110 Seat Retainer 21 66-115 Fluid Tube Assembly
4 98-8019 O-Ring* 22 60-2102 Trigger
5 66-103 Air Cap Adapter 23 66-121 Upper Filter Housing
6 66-102 Nozzle Carrier 24 66-119 Handle Plug
7 98-8014 O-Ring* 25 60-208 Spring
8 66-101 Gun Body 26 66-137 Spring Seat
9 60-1505 Fan Control 27 60-202 Fluid Control Knob
10 21-1001 Air Cap Ring 66-125 Filter (100 mesh standard)
11 26-101 Air Cap 66-124 Filter (60 mesh optional)
12 36-XXX Fluid Tip 29 66-118 Bracket
98-8007 O-Ring* 30 60-104 Air Inlet
36-100 Tip Strainer (Optional) 31 98-0186 Screw
14 60-1520 Air Valve 32 66-122 Filter Housing, Low er
15 60-119 Gasket 33 66-123 Filter Retaining Nut
16 60-201 Rear Bushing
17 60-1033 Trigger Pivot Assembly 10-127 Gun Repair Kit (soft seals only)
18 60-125 Air Valve Gasket 10-113
Re pair Kit s
Repair Kit
13
28
