C-SCOPE CS5MX - Page 3

Controls
89
CS2MX
10
11 12
CS2MX
CS5MX
8139
14
10
15 11 12
CS5MX
1 Battery Compartment
1
2
3
4
5
6
7
2 Upper Stem & Handle Grips
3 Din Plug & Socket
4 Stem Connecting Nut
5 Cable
6 Lower Stem
7 Search Head Fastener
8 Power On / Off & Sensitivity
9 All Metal Mode / Discrimination 1
10 Pinpoint
11 Disc 2 Select
12 Discrimination 2
13 Signal Meter (CS5MX only)
14 Boost Hi / Normal (CS5MX only)
15 Battery Check (CS5MX only)
