C.T.M. 5 series User Manual

Instruction Booklet5-Series
10
Detach the front and rear sections by holding the Seat Post (J) with one hand and the
other hand pushing the release lever to the rear of the scooter
. Lift the seat post to separate
the Rear Frame Assembly (H) from the Front Frame Assembly. (See Fig. 10 & 11)
By removing the front basket (K) and adjusting the tiller down by using the Steering
Column Lever (L), you should be able to place all parts in the boot and part of the rear seat.
(See Fig. 12)
Figure 10
Figure 10
Figure 11
Figure 11
(H)
(J)
Figure 12
Figure 12
(L)
(K)
