Instruction Booklet5-Series
6
FUNCTION OF PARTS：
TOP CONTROL PANEL
•Speed Control Knob
The Rabbit means fast and Turtle is slow. By turning this you control the total speed
transferred to the thumb controls.
•Self Diagnostic Warning Light
Flashing indicates problems with the scooter. See page 15 for more information.
•Battery Gauge
This light is yellow. Below it are three color ranges: red, yellow and green. When the
light is on in all three color ranges, the batteries are fully charged. When the light is on
only in the red, or red and yellow areas, the batteries need to be recharged.
BENEATH TOP CONTROL PANEL
•Thumb Levers
Pushing the right thumb lever moves the scooter forward. Pushing the left thumb lever
moves the scooter backward. (This can be reversed if required by local dealer.) Releasing
both engages the automatic brake. This is also your accelerator. The further you
depress them, the faster you go. (Subject to the position of the Rabbit/Turtle control).
AT BASE OF STEERING TILLER
•Steering Column Lever
Push downward on the handle to adjust. Pull up to lock Steering Column at comfortable
angle.
BELOW SEAT
•Seat Control Levers
Seat Control Slide - Lift up on lever under front edge of seat to adjust forward and
backward. Seat Rotation Lever - Push lever back to rotate seat; push forward to lock
seat in position.
•Thumbscrews
Loosen the two Thumbscrews to adjust the arm width; tighten again to lock the desired
position.
REAR BODY
•Rear Cover
Protects batteries from damage.
•Anti-tip wheels
Helps keep the scooter from tipping over.
•Free-Wheeling Lever
When lever is in the N (Neutral) position, the scooter can be moved without power.
When lever is in the D (Drive) position, the scooter can be driven. Normal position is D.
•Storage area
This is situated above the rear bumper.
