HS-898 Instruction Booklet
(O)
(H)
(a)
(b)
(Q)
(b)
(b)
(R)
(R)
(P)
Be careful when removing batteries, as batteries are heavy.
Do not contact battery terminal with any metals to avoid danger.
Figure 13
Figure 13
Figure 14
Figure 14
Figure 15
Figure 15
Figure 16
Figure 16
12
DISASSEMBLING YOUR SCOOTER
Disassembling Basket
By lifting the basket (O) upwards.
Disassembling Seat
By lifting lever (H) and seat (a) upward.
Rear Compartment Cover
Open the Compartment Cover (P) according to
arrow's direction.
Disassembling Batteries
Tear of
f battery straps (Q) and disconnect battery terminals (R) to remove the batteries (b).
-
+
