CAB SKYLINE 1 User Manual

REASSEMBLY OF THE TAP
Pic. 49
Pic. 47
Pic. 46
When inserting the main tap pin please be
careful that the little square hole (see Pic.
47) is placed right in front of you. Before
inserting the tap pin lubricate with
abundant water.
Keep the tap pin pressed upwards until
you are able to see the square hole where
you will insert the handle (see Pict. 48).
Insert the pin for handle fixing as indicated
in Pict. 49.
Before reassembling of the tap components lubricate by water the tap siege as indicated
in Pict. 45 and lubricate with abundant water the seals as indicated in Pict.47.
Pic. 45
HOLE
Insert the tap spring and tap pin as indicated in Pic. 45 and 46.
Pic. 48
LUBRICA
TE
I N
S I D
E
36
