Configuration 5.1 without the Max
■ 5 iO speakers + 1 Furio subwoofer or 2 main
speakers + 3 iO speakers + 1 Furio subwoofer
Connect each speaker output of the 5.1 amplifier directly to the
matching iO speaker (front right, front left, centre, etc.).
Connect the subwoofer CINCH RCA output of the amplifier to
one CINCH RCA LINE IN post of the subwoofer.
Then adjusts the set-up menu of your audio video amplifier:
For 5 iO speakers:
For 3 iO speakers and 2 large bandwidth front speakers:
FURIO SUBWOOFER ADJUSTMENTS
In any cases configuration 2.1 or configuration
5.1, the adjustment of frequencies CROSSOVER
FREQUENCY is positioned as follows:
The adjustment of the LEVEL will depend upon
room positioning, type of amplifier, etc. With the
Furio subwoofer, the average position of the LEVEL
control is as follows:
For an optimum adjustment of this level, we advise you to car-
ry it out starting from a stereo source (CD).
To adjust the level of the low frequency effect channel, do not
modify the sound level of the Furio subwoofer but go into the
set-up menu of your audio video amplifier 5.1 and adjust the
SUBWOOFER / LFE channel.
english
Because of technical improvements already under way in our constant search for optimum quality, Cabasse reserves the right to modify all the models
presented in specification sheets, advertising materials and manuals without prior notice.
Our web site www.cabasse.com will give you the specific adjustments we recommend for the use of our active subwoofers.
Installation 2/7 channels caisson de graves actif
Ways 2 1
Drivers tweeter-midrange 2 ways coaxial modèle 21M18LB4C - 21 cm
DOM25/13F15
Crossover frequency DOM25/13F15 à 2 700 Hz
Frequency bandwith 180 - 20 000 Hz 30 - 200 Hz
in semi-reverberating chamber in semi-reverberating chamber
Pulsed sound pressure 114dB
Efficiency 93 dB/2,8v/1m
High-pass filter 180Hz
Nominal impedance 8 ohms
Minimum impedance 3,2 ohms actif
Power handling 80 W 250 W
Peak power handling 560 W 750 W
Lowpass cut-off frequency from 40 to 180Hz
Phase switch 0°normal, 180 ° reverse
Input 2 low level, 2 high level
Magnetic shielding yes -
Max Cabasse module included yes
Voltage 115/230V, AC - 50/60 Hz
Maximum power consumption 165 W
Diameter of the sphere 16cm - 6.3 in
iO base version dimensions (hxwxd) 19x16x20 cm - 7.5x6.5x8 in 37 x 26 x 37 cm - 20x13x17 in
weight 2 kg - 4.9lb 18 kg - 40lb
iO stand version dimensions (hxwxd) 105x30x30 cm - 41.5 x 12 x 12 in
weight 10 kg - 21lb
iO in ceiling dimensions (hxwxd) 26 cm de diamètre
weight 2 kg - 4.9lb
SPECIFICATIONS iO SPEAKER SUBWOOFER FURIO
TECHNICAL DATA
FRONT
SMALL
CENTER
SMALL
SURROUND
SMALL
SUBWOOFER STEREO YES
SUBWOOFER / LFE YES
SUBWOOFER FREQUENCY 180Hz
FRONT
LARGE
CENTER
SMALL
SURROUND
SMALL
SUBWOOFER STEREO NO
SUBWOOFER / LFE YES
SUBWOOFER FREQUENCY 180 Hz
