CABASSE XI SYSTEM - Technical Features

english
Check all the connections carried out on the speakers, the
subwoofer and the amplifier. Ensure that each speaker is con-
nected according to its position
in the room. Check that all the
speakers are well in phase (+/red
in +/red and -/black in -/black).
Once this checking made you can
connect your amplifier and the
subwoofer to the sector.
ADJUSTING
Subwoofer adjusting
Take care of positioning the sector switch 115V/230V on the
right position according to your country.
The switch ON/OFF (located on the back) of the subwoofer has
3 positions:
ON
AUTO Automatic, the system is put automatically on ON or
OFF according to the presence of signal coming from
the amplifier. Put the switch ON/OFF on AUTO or ON
position.
OFF
CROSSOVER
0
(located on the front): adjust the poten-
tiometer on a “3 AM” position.
VOLUME (located on the front): the adjustment of the volume
will depend upon room positioning, type of amplifiers… With
Xi SYSTEM
®
the average position is on a “12 AM” position. For
an optimum adjustment of the volume, we advise you to car-
ry out it starting from a stereo source (CD). Then use the “test
tone” of your audio amplifier video 5.1 to adjust the level of
channel SUBWOOFER/LFE.
PHASE (located on the front): usually it is necessary to posi-
tion the potentiometer on 0°, however 2 positions can be
used 0° and 180 °.
1- Adjust the potentiometer on 0° when the subwoofer and the
speakers are positioned at the same distance of the listen-
ing area.
2- Adjust the potentiometer on 180° when the subwoofer is
positioned 5 ft (1.5m) ahead or behind the speakers.
Setting your audio video amplifier
-
The table below shows the adjustments to make.
Speakers Amplifier
adjusting
Front left LARGE
Front right LARGE
Centre LARGE
Surround Left LARGE
Surround Right LARGE
Subwoofer/LFE ON
Xi SYSTEM
®
Position Installation Ways Drivers Sensivity Cross-Over Phase Frequency
Tweeter Medium* 1W/1m points response
(cm) (cm) (dB) (Hz) (Hz)
Xi Speaker floorstanding
2/5/6/7 2 SOFTDOME 4 in (10 cm) 92.5 3,500 - 150-20,000
column
channel system 1 in (2.6 cm) x2
Xi Speaker bookshelf
2/5/6/7 2 SOFTDOME 4 in (10 cm) 92.5 3,500 - 150-20,000
bookshelf or stand
channel system 1 in (2.6 cm) x2
Xi Speaker on/under TV
2/5/6/7 2 SOFTDOME 4 in (10 cm) 92.5 3,500 - 150-20,000
centre/on wall on wall
channel system 1 in (2.6 cm) x2
Xi subwoofer floorstanding subwoofer 1 - 21 active adjustable adjustable 30-170
0°-180°
Set of 2 aluminium stand in option
XI SYSTEM
®
TECHNICAL FEATURES
*P2C diaphragm : Polymer loaded in Calcium Carbonate
Caution
To prevent the risks
of electric shock
takes care to completely
insert plugs
of sector cords.
