Cabela's 551306 - Page 13

12
4. Place pot on cooker with wire harness assembly in line with the venturi tube as shown in Figure 3.
Attach pot connector to thermocouple connector as shown in Figure 4. These must be attached for
the outdoor cooker to operate.
FIGURE 3
FIGURE 4
* Model May Vary From Picture
* Model May Vary From Picture
Pot Connector
Thermocouple
Connector
Venturi
Wire Assembly
Pot
