Operation and Function
Power Connections-These connections are for input power, chassis ground,
and remote turn-on. Use a minimum of 18 gauge wire for power and ground
connections. The power wire should be fused with a 1 amp fuse.
RCA Front & Rear Outputs- These RCA output jacks provide a full range
signal to your amplier.
RCA Inputs- These RCA input jacks allow for a normal left and right channel
signal input from the source unit.
RCA Sub Outputs- These RCA output jacks provide a LP signal to your
bass amplier.
AUX Input Gain Adjustment- This control matches the input level of your cpa
with the output level of the source unit connected to the Aux input. When
properly adjusted both sources (AUX and MAIN) should play at the same
volume level. The adjustments are individual with one for the left channel
and one for the right channel.
LPF Frequency Adjustment- This controls the cutoff frequency of the LPF
on the "SUB OUT" channels. The lter is variable from 50Hz to 150Hz.
Volume Control- This raises and lowers the volume on all the cpa's outputs
simultaneously.
Subwoofer Level Adjustment- This raises and lowers the level of just the
"SUB OUT" channels.
Fader Adjustment- This allows you to adjust the level between the "Front"
and "Rear" channels.
Illumination Selector- Changes illumination around controls to red or blue.
AUX Input Switch- This switch is used to select the input of the cpa. When
the button is pressed in the "AUX" input is seleced. In normal position the
main input is active.
Equalizer level Adjustment- There are seven different frequencies or bands
that can be adjusted. Each band has an available adjustment of +/-10dB.
A
B
C
D
E
F
H
G
L
J
K
I
