25
Model 1027
Ref. No. Part No. Description
1.
683-0155A Brake Pedal Assembly
2.
683-0161 Shift Cam Assembly
3.
683-0275A Deck Pedal Assembly
4.
683-0310A Variable Pedal Assembly
5.
710-1017 Ab Screw 1/4-14 X .625
6.
711-0701 Clevis Pin
7.
711-1156 Shaft
8.
712-0287 Hex Nut 1/4-20
9.
712-0324 Lock Nut 1/4-20
10.
712-3017 Hex Nut 3/8-16
11.
714-0104 Internal Cotter Pin
12.
714-0111 Hairpin Clip
13.
714-0470 Hairpin Clip
14.
720-0166 Ball Knob
15.
726-0100 Push Cap
16.
726-0450 Plug Cap
17.
731-0405 Snap-on Bushing
18.
731-1913 Stop Lever
19.
732-0815A
Extension Spring
20.
732-0865 Torsion Spring
21.
735-0261 Drive Pad
22.
735-0262 Deck Pad
23.
735-0263
Brake Pad
24.
736-0117 Flat Washer 3/8 X .620 X .033
25.
736-0133 Flat Washer.411 x 1.25” x .100
26.
736-0159 5/16 Washer
27.
736-0169 Lock Washer
28.
736-0187 Flat Washer
29.
736-0262 Flat Washer
30.
736-0272 Flat Washer .510 X 1.00 X .060
31.
736-0300 Flat Washer
32.
736-0329 Lock Washer
33.
736-0608 Spring Washer
34.
736-3000 Flat Washer
35.
736-3019 Flat Washer .531 X 1.062 X .134
36.
736-3020 Flat Washer .271 X .630 X .065
37.
738-0255 Shoulder Screw .375 Dia X .18
38.
738-0373 Shoulder Screw
39.
738-0974 Shoulder Screw .375 X .380 X 1/4-20
40.
741-0591 Flange Bearing
41.
746-0935A Shift Cable
42.
746-0936 Variable Drive Cable
43.
746-0937 Brake Cable
44.
746-0940 Deck Cable
45.
746-0964 Throttle Choke Cable: 67”
46.
747-0963A Brake Rod
47.
747-0964 Brake Lock Out Rod
48.
750-0736 Shoulder Spacer
49.
783-0473 Brake Lock Out Bracket
50.
783-0525 Self-Propelled Pedal Link
51.
783-0593A Shift Lever
52.
783-0794 Bracket: Lock-Out Pedal
53.
726-0157 Cable Tie
Ref. No. Part No. Description
