6-62
Underhood Fuse Block
The underhood fuse block is located next to the air
cleaner on the driver’s side of the engine. Lift the cover
to gain access.
Fuse Usage
CNR LPS Cornering Lamp Switch, Right
and Left Cornering Lamps
INT LPS Trunk Lamp, Courtesy Lamps,
Front Vanity Lamps, Glove Box
Lamp, Garage Door Opener,
Courtesy Lamp Relay
To Next Page
