6-64
Fuse Usage
PCM (BAT) PCM
PARK/REV Reverse Relay, Right and Left
Back
-Up Lamps, Electrochromic
Mirror (in Header), Park Relay,
Automatic Transaxle Shift Lock
Control Switch
ECS Transaxle Shift Solenoids,
Air Meter, Canister Purge, PCM,
Front Ignition
-1 Relay
PCM (IGN) Powertrain Control
Module (PCM)
DIS Odd and Even Coil Packs
CRUISE Stepper Motor Cruise Control,
Low Refrigerant Pressure Cutoff
Switch, Park Relay
Fuse Usage
INJ Injectors 1, 4, 6, 7
INJ Injectors 2, 3, 5, 8
FUEL PUMP Fuel Pump Relay, Fuel Pump
OXY SEN1 Oxygen Sensor Front
OXY SEN2 Catalytic Converter (CAT)
Rear Oxygen Sensor, Starter
Enable Relay
Relays
A/C COMP
RELAY
FUEL PUMP
RELAY
To Next Page
