6-45
4. Turn on the low-beam headlamps and place a piece
of cardboard or equivalent in front of the headlamp
not being aimed. This should allow only the beam of
light from the headlamp being aimed to be seen on
the flat surface.
NOTICE:
Do not cover a headlamp to improve beam
cut
-off when aiming. Covering a headlamp may
cause excessive heat build
-up which may cause
damage to the headlamp.
5. Turn the vertical aiming screw (V) until the headlamp
beam is aimed to the horizontal tape line. The top edge
of the cut-off should be positioned at the bottom edge
of the horizontal tape line.
6. Repeat Steps 4 and 5 for the opposite headlamp.
