4-8 Storage
Storing the Fence
1. Lift the cargo management
system cover.
2. Release the cover from the prop
rod as described in the previous
steps.
3. Insert the top of the fence into
the lower two clips (A).
4. Turn the bottom of the fence up
and insert it into the upper two
clips (B).
D-Ring Sliders
For vehicles with a D-ring system,
there are four D-ring sliders that
move along rails. These can be
used as tie-downs when storing
cargo.
Insert the D-ring sliders (A) into the
channel (B) located in the middle of
the rail. Push the button to move the
D-ring slider along the rail.
The loop of the D-ring slider must
be facing inward towards the
storage area and the ring must be in
the up position for proper usage.
