Cadillac STS 2005 - Instrument Panel Cluster

STS
INSTRUMENT PANEL CLUSTER
1. Engine Coolant Temperature
Gauge
2. Turn Signal Indicator Lights
3. Tachometer
4. High Beam Indicator Light
5. Speedometer
6. Tire Pressure Light
7. Fuel Gauge
8. Traction Control System
Warning Light
9. Antilock Brake System
Warning Light
10. Brake System Warning Light
11. Air Bag Readiness Light
12. Cruise Control On Light
13. Driver Information Center Display
14. Charging System Light
15. Oil Pressure Light
16. Malfunction Indicator Lamp
(Service Engine Soon Light)
17. Safety Belt Reminder Light
18. Security Light
19. Fog Lamp Light
1
2
2
3 5
6 7
8
9
12
4
14
15
16
13
11
19
10
17
18
Note:
Some of the gauges and indicators
may differ from the illustration presented.
