Cadman 1100 - Page 35

TR-MAN-1100
Operator's Manual - Micro-Travellers
Page 34 of 68
Cadman Power Equipment ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com
Frame Assembly
Item
Description
Part Number
Qty
1
ROUGH TOP BELT - 1 3/8" x 5"
40-093-05
3
2
HAND GRIP - 0.75 X 4.00
42-019
2
3
LABEL - MAX TOW SPEED
42-033-A
1
4
LABEL - OPERATOR MANUAL
42-050-A
1
5
SPRING PLUNGER - HAND RETRACTABLE
42-547
1
6
LABEL - DISCONNECT
42-LBL-007
1
7
DECAL - 1100 SIDE FRAME
42-LBL-1100-L-A
1

DECAL - 1250 SIDE FRAME L.H.
42-LBL-1250-L-A
1
8
DECAL - 1100 SIDE FRAME
42-DCL-1100-R-A
1

DECAL - 1250 SIDE FRAME R.H.
42-DCL-1250-R-A
1
9
WHEEL AND RIM ASSY
55-162
2
10
KIT - BATTERY BOX
61-625-000
1
11
TONGUE WELDMENT - 1100
68-200-000
1
12
HANDLE/CLEVIS WELDMENT - 1100
68-201-000
1
13
FRAME WELDMENT - 1100/1250
68-400-000-A
1
14
BOLT - 3/8-16 X 2 1/2
90-BLT-03816X250
1
15
BOLT - 3/8-16 X 2 3/4
90-BLT-03816X275
1
16
NUT ACORN - 3/8-16UNC
90-NUT-ACN038-16
2
17
COTTER PIN, 3/16 X 1.75 LG
90-PIN-CT019X175
4
18
QUICK PIN - 3/8 X 2 1/2 LG.
90-PIN-Q038X250
2
19
TEK SCREW - 1/4" X 3/4"
90-SCR-TEK025X075
2
20
WASHER SAE - 3/8
90-WSR-SAE038
4
21
WASHER SAE - 3/4
90-WSR-SAE075
4
22
MANUAL PAK - SMALL ASSEMBLY
TR-MAN-SMPAK
1
