TR-MAN-1100
Operator's Manual - Micro-Travellers
Cadman Power Equipment ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com
Technical Specifications
Approximate 1100/1250 Micro-Traveller Dimensions
IMPORTANT: The dimensions shown on the following pages are only approximate. Many
varying factors affect these dimensions, for example tire option, hose type, tire inflation etc.
Figure 41 – Overall 1100/1250 Dimensions with Low Sprinkler Cart
img-00754
The approximate weight for an empty Cadman 1100 Micro-traveller is 525 lbs [232 kg].
The approximate weight for an empty Cadman 1250 Micro-traveller is 525 lbs [232 kg].
Note: These weights are as shipped including shipping material.
