Frame Assembly Continued
Item
Description
Part Number
Qty
1
CADMAN SERIAL NUMBER TAG
40-238
1
2
SPRING
42-006
1
3
SPRING EXTENSION
42-313
2
4
SHUT OFF SWITCH - BUTTON STYLE
42-ELC-043
1
5
CLAMP - M6 26-28 (1.02-1.13)
50-075
1
6
HARNESS - POTENTIOMETER
61-313-A
1
7
BRACKET - SPEED COMP.
61-314
1
8
SUPPORT - SHUT OFF BAR
61-614-000
1
9
STOP - 1.00" COLLAR
61-621-000
2
10
STOP - 1/2" SHUT OFF BAR
61-623-000
1
11
TUBE RIDER WELDMENT - 1100
68-604-000
1
12
SHUTOFF BAR WELDMENT - 1100
68-605-000
1
13
FOOT - REVERSIBLE
68-606-000
2
14
SHIELD WELDMENT - INDEXER
68-610-000
1
15
LINK - 1100 SPEED COMP.
68-619-000-A
1
16
HOSE FLANGE WELDMENT - 1100
68-910-000
1
17
BOLT - #08-32 X 3/4
90-BLT-00832X075
2
18
BOLT CARRIAGE - 1/2-13 X 1 1/2
90-BLT-CG05013X150
2
19
BOLT ELEVATOR - 5/16-18 X 3
90-BLT-EL03118X300
1
20
BOLT FLANGE HEAD - 5/16-18UNC X 3/4
90-BLT-F03118X075
10
21
BOLT FLANGE HEAD - 3/8-16UNC X 3/4
90-BLT-F03816X100
4
22
NUT HEX - 5/16-18
90-NUT-HEX031-18
1
23
THREADED INSERT - 5/16-18 SHORT
90-NUT-HTR03118S
6
24
NUT LOCK - #06-32
90-NUT-LOC006-32
2
25
NUT LOCK - #08-32
90-NUT-LOC008-32
2
26
NUT LOCK - 1/2-13
90-NUT-LOC050-13
2
27
COTTER PIN - 1/8 X 1.00 LONG
90-PIN-CT013X100
1
28
RIVET - 3/16 X 3/8 IN
90-RIV-019X038
2
29
MACHINE SCREW PAN - #6-32 X 1 1/8 PHILLIPS
90-SCR-PH00632X113
2
30
WASHER FLAT - 1/2
90-WSR-FLT050
2
31
GASKET - 1 1/4" X 2 BOLT
IR-GKT-2B125
1
