Drum Assembly
Item
Description
Part Number
Qty
1
BEARING BLOCK PLATE
27-634
2
2
HOUSING - SWIVEL MACHINE
33-326
1
3
GEAR SEGMENT - 120 TEETH
33-625-A
1
4
LABEL - ENTANGLEMENT
40-051-A
1
5
O-RING - 1 5/8 ID X 2 OD X 3/16 W
42-037
1
6
SEAL – EDGE 36.83”
42-303
1
7
DECAL - DRUM R10 1/4"
42-DCL-006
4
8
HOSE - 1.30” OD X 1.10” ID X 250ft - 1100
50-116-250
1

HOSE - 1.45” OD X 1.24” ID X 230FT - 1250
50-144-230
1
9
BEARING - Ø 1 5/16" UHMW BLACK
68-303
1
10
FRAME WELDMENT - 1100/1250
68-400-000
1
11
DRUM WELDMENT - 1100
68-501-000
1

DRUM WELDMENT - 1250
68-551-000
1
12
SHIELD - INDEXER CHAIN
68-610-100
1
13
DRIVE SHILED WELDMENT - 1100
68-610-200
1
14
BOLT FLANGE HEAD - 5/16-18UNC X 3/4
90-BLT-F03118X075
11
15
BOLT FLANGE HEAD - 5/16-18 X 1 1/2"
90-BLT-F03118X150
2
16
NUT ACORN - 3/8-16UNC
90-NUT-ACN038-16
4
17
NUT HEX - 3/8-16
90-NUT-HEX038-16
4
18
THREADED INSERT - 5/16-18 SHORT
90-NUT-HTR03118S
9
19
NUT LOCK - 5/16-18
90-NUT-LOC031-18
2
20
THREADED ROD - 3/8-16 X 4 3/8"
90-ROD-03816X0438
4
21
WASHER FLAT - 5/16
90-WSR-FLT031
2
22
CAM LOCK - F150
IR-CAM-150/F
1
