Cadman 1100 - Page 41

TR-MAN-1100
Operator's Manual - Micro-Travellers
Page 40 of 68
Cadman Power Equipment ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com
Indexing System
Item
Description
Part Number
Qty
1
IDLER WHEEL - RUB BLOCK
08-653
1
2
ROLLER CHAIN - #40 RIVETED
10-CHN-40-1RIV/FT
14.38
3
CONNECTING LINK - #40-2
10-LNK-40-2CONN
1
4
CONNECTING LINK - #40
10-LNK-40CONN
3
5
SPROCKET - 40B09 X 1/2"
10-SPT-40B09X050
1
6
SPROCKET - 40B09 X 14mm
10-SPT-40B09X14MM
1
7
SPROCKET - 40B36 X 14MM BORE
10-SPT-40B36XM14
1
8
INDEXER DRIVE BUTTON
33-301
1
9
SPACER - IDLER SPROCKET
37-304
1
10
IDLER SUPPORT MACHINE
37-306
1
11
GREASE FITTING - 1/8 NPT
40-001
2
12
GEARBOX - RIGHT ANGLE
42-588
1
13
IDLER WHEEL - RUB BLOCK
61-301
1
14
HOSE GUIDE WELDMENT – 1100/1250
68-607-000-A
1
15
BAR - INDEXER
68-608-000
1
16
SHAFT - INDEXER IDLER WELDMENT
68-627-000
1
17
BOLT - 1/2-13 X 2.00
90-BLT-05013X200
1
18
BOLT FLANGE HEAD - 1/4-20 X 1.00
90-BLT-F02520X100
4
19
BOLT FLANGE HEAD - 1/4-20 X 3 1/2
90-BLT-F02520X350
4
20
BOLT FLANGE HEAD - 5/16-18UNC X 3/4
90-BLT-F03118X075
2
21
NUT FLANGE - 1/4-20 SERRATED
90-NUT-F025-20
8
22
NUT LOCK - 1/2-13
90-NUT-LOC050-13
1
23
WASHER FENDER - 3/8" X 1 1/2"
90-WSR-FEN038
1
24
WASHER FLAT - 1/2
90-WSR-FLT050
3

