Cadman 1100 - Page 43

TR-MAN-1100
Operator's Manual - Micro-Travellers
Page 42 of 68
Cadman Power Equipment ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com
Drive System
Item
Description
Part Number
Qty
1
ROLLER CHAIN - #40 RIVETED
10-CHN-40-1RIV/FT
14.38
2
IDLER SPROCKET - 40-18 X 5/8
10-SPT-40-18IDLER
3
3
40B15 X 3/4 SPROCKET
10-SPT-40B15X075
1
4
RUBBER BUMPER
42-063
1
5
TOGGLE CLAMP - PUSH/PULL 3/4"
42-587
1
6
FLANGE BEARING - 3/4"
42-BRG-5913K73
2
7
CONTROLLER - iWATER™ MINI
42-ELC-033-A
1
8
MOTOR - MINI-TRAVELLER
42-ELC-034
1
9
DRIVE SHAFT
61-300-000-A
1
10
DRIVE CLUTCH
61-305
1
11
CLUTCH - DRIVEN
61-306
1
12
YOKE - DOUBLE IDLER SPROCKET
61-632-000
1
13
DRIVE SYSTEM MOUNT WELDMENT
61-651-000-C
1
14
YOKE - DRIVE DISENGAGE
61-652-000-A
1
15
BRACKET - DOUBLE IDLER
67-631-000-A
1
16
BOLT - 1/2-13 X 3.25
90-BLT-05013X325
1
17
BOLT FLANGE HEAD - 1/4-20 X 1.00
90-BLT-F02520X100
5
18
BOLT FLANGE HEAD - 5/16-18 X 1.00
90-BLT-F03118X100
4
19
BOLT - 1/2-13 X 2 1/2 F/THREAD
90-BLT-FT05013X250
2
20
KEY - 3/16" X 3/8" X 1 7/8"
90-KEY-SQ019X038X163
1
21
3/16 SQ. X 1 1/8" LG. KEY
90-KEY-SQ019X113
1
22
NUT HEX - 5/16-18
90-NUT-HEX031-18
2
23
NUT FLANGE - 1/4-20 SERRATED
90-NUT-F025-20
2
24
JAM NUT - 5/16"-18
90-NUT-JAM031-18
1
25
JAM NUT - 1/2"-13
90-NUT-JAM050-13
2
26
NUT LOCK - 1/4-20
90-NUT-LOC025-20
4
27
NUT LOCK - 1/2-13
90-NUT-LOC050-13
1
28
NUT RED. COUPLER - 1/4-20 X 5/16-18
90-NUT-RCPL02520X03118
1
29
CLEVIS PIN - 1/2 X 1 3/4 LG
90-PIN-CL050X175
1
30
COTTER PIN, 7/64 X 3/4 LG
90-PIN-CT011X025
2
31
THREADED ROD - 1/4-20 X 3.00"
90-ROD-02520x0300
1
32
THREADED ROD - 51/6-18 X 7.00"
90-ROD-03118X0700
1
33
SCREW SOCKET CAP - #08-32 X 1/2
90-SCR-SH00832X050
4
34
SCREW SOCKET CAP - M06-100 X 20MM
90-SCR-SHM06100X20
4
35
SET SCREW - 10-32 X 5/16 LG
90-SCR-ST01032X031
2
36
EXTENSION SPRING - 11/16 X .105 X 4 1/16
90-SPG-068X105X406
1
37
SPACER - 1/2 ID X 5/8 OD X 3/4
90-SPR-051X063X075
1
38
WASHER FLAT - 1/4
90-WSR-FLT025
4
39
WASHER FLAT - 1/2
90-WSR-FLT050
4
40
WASHER LOCK - M06 HIGH COLLAR
90-WSR-LOCM06HC
4
41
WASHER SAE - 5/16
90-WSR-SAE031
2
42
WASHER SAE - 1/2
90-WSR-SAE050
9
