Wiring Assembly
Item
Description
Part Number
Qty
1
SHUT OFF SWITCH
40-ELC-043
1
2
FEMALE SPADE - 1/4" BLUE - 16-14 GAUGE
40-068
2
3
5/16 IN. EYE TERM. YELLOW - 12-10 GAUGE
40-322
2
4
SWITCH - EMERGENCY STOP
42-268
1
5
CONNECTOR - BATTERY
42-311
2
6
BATTERY - 12V 33AH
42-325
1
7
ROTARY POTENTIOMETER 10K OHM
42-ELC-032
1
8
CONTROLLER - iWATER™ MINI
42-ELC-033-A
1
9
MOTOR - MINI-TRAVELLER
42-ELC-034
1
10
HARNESS - MOTOR PLUG & WIRING
42-ELC-034_PLUG
1
11
PANEL - iWATER™ MINI
42-ELC-035-A
1
12
HARNESS - iWATER™ MINI PLUG & WIRING
42-ELC-035-A_PLUG
1
13
TERMINAL - BLUE SPADE 16-14 GA.
42-ELC-036
2
14
Terminal Blocks Pluggable plug, 4 position
42-ELC-046
1
15
Terminal Blocks Pluggable plug, 5 position
42-ELC-047
1
16
HARNESS - BATTERY PLUG
61-310
1
17
HARNESS - MAIN
61-311-A
1
18
HARNESS - POTENTIOMETER
61-313-A
1
AR
CABLE TIE - ANCHOR MOUNT BLACK (NOT SHOWN)
42-595
11
AR
CABLE TIE – 4 IN. BLACK (NOT SHOWN)
40-391
11
