CAKEWALK CA-2A - Controls

11
Controls
There are two versions of the CA-2A T-Type Leveling Amplifier interface: one version for VST
and Audio Units plug-ins, and one version for the SONAR ProChannel module.
Figure 3. VST and Audio Units (AU) controls.
A. VU meter B. VU meter mode C. Options menu D. Limit/Compress E. R37 F. Gain G. Peak
Reduction H. Enable/disable
Figure 4. SONAR ProChannel module controls.
A. Clipping LED B. CA-2A T-Type Leveling Amplifier enable/disable C. VU meter D. Limit/Compress
E. VU meter mode F. Gain G. Options menu H. R37 I. Peak Reduction
A B
D F G HE
C
B
H
D
A
I
F
C
E
G
